1.5T Wheel Loader DH1600

Engine

Overall Dimensions

Model

Xinchai 498,Euro 5.

Overall Length

5049mm

Engine type

In-line arrangement, water-cooled,

four-cycle diesel Engine

Overall Height

2500mm

Rated Power

36.8KW

Overall width

1700mm

Rated Speed

2200 r/min (rpm)

Dumping Height

2655mm

Fuel Consumption

210g/kw.h

Transmission System

Brake System

Type

Fixed-spindle Power shift

Service Brake

Four Wheel Hydraulic spread-shoe brake

Shift gear control oil pressure

1.2~1.5MPa

Parking Brake

Hand operated

Bucket

Operating Specifications

Bucket Capacity

0.7 m3

Steering System

Articulated Frame with hydraulic power steering

Bucket width

1750mm

Min Turning Radius

4300mm

Max. Breakout Force

36.8KN

Driving System

Hydraulic converter

Rated Load

1500kg

Tire

Operating Weight

3700kg

Size

400/60-15.5 vacuum tire

Note: The technical information , pictures may be a little different to the real product , any amendments changes without notice , we reserve the right of final interpretation .
