Home      Products     Crawler Excavator       3.6Ton Crawler Excavator DH36
  • 3.6Ton Crawler Excavator DH36
  • 3.6Ton Crawler Excavator DH36
  • 3.6Ton Crawler Excavator DH36
3.6Ton Crawler Excavator DH363.6Ton Crawler Excavator DH363.6Ton Crawler Excavator DH36

3.6Ton Crawler Excavator DH36

3.6Ton Small Hydraulic Crawler Excavator DH35 Specifications :

Dimensions

Operating Weight

3600KG

Overall Length

4400(MM)

Overall Height

2200(MM)

Upper/Bottom chassis width

1530/1600(MM)

Track width

300(MM)

Track gauge

1703(MM)

Platform ground clearance

557(MM)

Operating

Range

Max.Digging radius

4730(MM)

Max.Digging distance

4630(MM)

Max.Digging depth

2545(MM)

Max.Digging height

4450(MM)

Max.Dumping  height

3050(MM)

Min.Rotation radius

1820(MM)

Tail Swing radius

1170(MM)

Max.lifting height of dozer blade

359(MM)

Max.digging depth of dozer blade

268MM

Engine

Engine

3TNV88

Rated Power

19.6KW

Cooling Type

Water-cooling diesel engine

Hydraulic System

Rated Pressure

22mpa

Travel Motor

Two speed Plunger

Swing Motor

Variable Plunger

Main Pump

Variable Plunger pump

Max.Flow

99/min

Performance

Gradeability

35°

Max.digging force Bucket/ArmISO

55.6KN5560

Travel Speed( steel tracks)

2.7/4.6km/h

Swing Speed

9-11r/min

Bucket Capacity SAE

0.26m³

Fuel Tank Capacity

60L

Hydraulic Tank Capacity

75L
