DH35 Hydraulic Excavator with Kubota Euro 5

ENGINE

TRACK DRIVING SYSTEM

Emission Standard

Euro 5,EPA4

Maximum Travel speed(High/low)

4.4/2.4km/h

Make /Model

KUBOTA /D1703

Width of steel track shoe

300mm

Power /Rotation speed

18.5kw(25HP)@2200rpm

Carrier roller(Each side)

1

Number of cylinder

3

Supporting roller(Each side)

4

Type

In-line,water cooled, 4-stroke ,mechanical pump

PERFORMANCE PARAMETER

Max.torque

97.4N.m/1500rpm

Standard Bucket capacity

0.12m³

Displacement

1.642L

Swing speed

9rpm

MACHINE SIZE

Maximum Grade ability

58%(30°)

Overall dimension (L*W*H)

4915mm*1720mm*2525mm

Ground pressure

32Kpa

Axle base(Track length on ground)

1670mm

Maximum Bucket digging force

30.4KN

Length of rubber track

2154mm

Maximum Arm digging force

18.2KN

Track gauge

1420mm

Hydraulic system pressure

22.5Mpa

Minimum Ground clearance

295mm

Machine weight

3810kg

Swing radius at tail

860mm

Boom length

2535mm

Swing radius at front

2538mm

Arm length

1400mm

Height of blade

350mm

Fuel tank capacity

42L

WORKING RANGE

Hydraulic oil tank capacity

48.5L

Maximum Digging height

4800mm

Engine oil capacity

7L

Maximum Dumping height

3406mm

Radiator capacity

3.8L

Maximum Digging depth

3208mm

Final drive

2*0.7L

Maximum Vertical digging depth

2957mm

Maximum Digging distance

5480mm

Maximum digging distance (on ground)

5359mm

Minimum swing radius

2530mm

Max.height when min.swing radius

3655mm

Maximum Lifting height of blade

365mm

Maximum Cutting depth of blade

385mm

Boom swing angle(Left/Right)

55°/65°
